IP65 Anti-glare Ra93 Dustproof CREE Led Downlight
Adopt top brand CREE COB LED.
High Ra93/Ra83 CRI for good coloration, Anti-glare optical design.
No UV and near-IR radiation in the light beam.
Environment friendly, without Mercury.
Correspond CE ,RoHS
Long lifetime up to 50,000 hours.
Great Reliability supports 3-5 years warranty.
Parameters
| Item Number | JDL11-8W | JDL11-12W | |||
| Power | 8W | 12W | |||
| Fixture Luminous Flux | 680lm | 1020lm | |||
| Fixture Efficiency | 85lm/W-90lm/W | ||||
| Installation | Recessed on ceiling installation | ||||
| LED chips | CREE COB LED | ||||
| CRI | 83/93 | ||||
| Color temp | 3000K (2700K,4000K,5000K optional) | ||||
| Beam Angle | 38° | ||||
| IP rating | IP65 | ||||
| Dimmable | Available | ||||
| Input voltage | 200-240Vac ,47-63Hz | ||||
| PF | ≥0.60 | ||||
| Operating Temperature | 0℃ ~ +40℃ | ||||
| Storage Temperature | -5℃ ~ +55℃ | ||||
| Materials | Aluminum /PC | ||||
| Compliance | EMC,LVD,ROHS | ||||
| Cut-out size | Φ75mm-80mm | ||||
| Dimension | Φ90*90mm | ||||
| Package size | Box size | 95*95*100mm(1pcs) | |||
| Outer carton | 540*285*490mm(50pcs) | ||||
| Net weight | 14.0Kg | ||||
| Gross weight | 16.0Kg | ||||
